ZR160L Hydraulic Piling Rig 56M Rotary Foundation Drill Rig
Product Details:
| Place of Origin: | china |
| Brand Name: | ZOOMLINE |
| Certification: | CE、ISO9001 |
| Model Number: | ZR160L |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Overall transport; Packaged in one flat rack. |
| Delivery Time: | confer with |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5 set per month |
|
Detail Information |
|||
| Name: | Rotary Foundation Drill Rig | Brand: | ZOOMLINE |
|---|---|---|---|
| Model: | ZR160L | Torque: | 160(KN.M) |
| Drilling Diameter: | 1500(mm) | Drilling Speed: | 5～35(r/min) |
| High Light: | ZR160L Hydraulic Piling Rig,1500mm Hydraulic Piling Rig,56M rotary foundation drill rig |
||
Product Description
ZOOMLINE ZR160L Rotary Foundation Drill Rig 56M
ZOOMLINE ZR160L Rotary Foundation Drill Rig Feature
High efficiency: Large core parameters such as high torque and crowd force; fast line speed of main rope to ensure high drilling efficiency in hard soil layer; it is suitable for overpass, high-speed rail, large buildings and other large hole foundation fields.
Full stroke crowd: Adopt winch crowd system with 17-meter super long stroke, fast crowding, rotary drive display function, suitable for all casing construction in beach, pebble and backfill formation.
Economy and energy saving: Power optimization control technology is adopted to distribute power in real time with smooth and fast response of composite action; Moreover, it has high fuel efficiency and low comprehensive fuel consumption.
ZOOMLINE ZR160L Rotary Foundation Drill Rig Parameters
|
Torque(KN.M)
|
160
|
|
|
Drilling Diameter(mm)
|
1500
|
|
|
Drilling Depth(m)
|
inter-locking
|
44
|
|
Friction
|
56
|
|
|
Drilling Speed(r/min)
|
5～35
|
|
|
Engine Model
|
QSB5.9
|
|
|
Rated Power(kw)
|
154
|
|
|
Max.Crowd Force(kN)
|
160
|
|
|
Max.Crowd Cylinder Pull(kN)
|
160
|
|
|
Line Pull(main winch)(kN)
|
160
|
|
|
Line Speed(main winch)(m/min)
|
82
|
|
|
Line Pull(aux.winch)(kN)
|
60
|
|
|
Line Speed(aux.winch)(m/min)
|
80
|
|
|
Operating Mass(t)
|
50
|
|
|
Traction Force(kN)
|
330
|
|
|
Rope diameter(Main winch)(mm)
|
26
|
|
|
Rope diameter(auxiliary winch)(mm)
|
18
|
|
ZOOMLINE ZR160L Rotary Foundation Drill Rig Pictures
