169KW Hydraulic Piling Rig FDH5 Hydraulic Rotary Piling Rig 13m
Product Details:
| Place of Origin: | china |
| Brand Name: | FDM |
| Certification: | CE、ISO9001 |
| Model Number: | FDH5 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Overall transport; Packaged in one flat rack. |
| Delivery Time: | confer with |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 5 set per month |
|
Detail Information |
|||
| Name: | FDH5 Hydraulic Piling Rig | Brand: | FDM |
|---|---|---|---|
| Model: | FDH5 | Drilling Diameter: | 13M |
| Max Drilling Depth: | 60/50m | Rated Power: | 169KW |
| High Light: | 169KW Hydraulic Piling Rig,13m Hydraulic Piling Rig,50m hydraulic rotary piling rig |
||
Product Description
FDH5 Hydraulic Piling Rig 13m
Hydraulic Piling RigFeature
YD pile dier is a ne bype of pile nmachiney whichwas anatirockscod in 2010. According lo dfterent haemmewweght there are FDHS FDHR FDH1O FDH12HDH6HDH20 and other models of a pile drivers,The hyolraule pilehsarmmer is drlvens into the osround by Mfting the hamameshead and diropping the hamrner cap and pile with the piston rod of the hydiauic oop sper ially dedgned and stee pipepia wuare pile and pocast pilk with the diameter of can be coemstruactil ie the oil cyindewhas the fast ol cylnce and the stide is autonaticallyacjustable may 1ealze the licht hit and the heanvy hit Whenthe hydraulc pile hammer is removed the hydraule powehead the preoAlre oyiader. the tokesoopic dil Red and thedilbit of the top spin drillng nig are replaced
Hydraulic Piling Rig Parameters
| Parameter | ||
| Type | FDH5 | |
| Drilling diameter | 600-1600mm | |
| Max drilling depth | 13m | |
| Overall measurement | Working dimensions | 18950mmX4200mmX7297mm |
| Transport dimensions | 14727mmX3200mmX3325mm | |
| Rotary drive | Torque | 180kn-m |
| Rotation speed | 5/30rpm | |
| Crowd cylinder | Max.push | 160kn |
| Max.pull | 100kn | |
| Max.stroke | 3000mm | |
| Main winch | Max line pull | 150kn |
| Max.line speed | 70m/min | |
| Auxiliary winch | Max line pull | 60kn |
| Max.line speed | 50m/min | |
| Engine | Rated power | 169KW |
| Type | QSB7 Cummins | |
| Electronic Managerment system | Long distance montitor system | Available |
| Drilling record system | Available | |
| On car printer | Available | |
| hydraulic system pressure | 300bar | |
| Chassis | Chassis modality | Custom |
| Max.traveling speed | 3km/h | |
| Min.ground clearance | 400mm | |
| Windth of track shoes | 700mm | |
| Leveling around | Free adjustment forward/backward | 0-100° |
| Free adjustment left/right | 士3° | |
| Machine Weight | 45000kg |
FD188A Hydraulic Piling Rig Pictures
